Ibanez Hollow Body Gtr AS93PSBK

• neck type
• AS Expressionist3pc Nyatoh/Mapleset-in neck

• top/back/side
• Linden top Linden backLinden sides

• fretboard
• Bound Macassar Ebony fretboardTree of Life inlay

• fret
• Medium frets

• number of frets
• 22

• bridge
• Gibraltar Performer bridge

• string space
• 10.5mm

• tailpiece
• Quik Change Classic tailpiece

• neck pickup
• Super 80 (H) neck pickupPassive/Ceramic

• bridge pickup
• Super 80 (H) bridge pickupPassive/Ceramic

• factory tuning
• 1E,2B,3G,4D,5A,6E

• strings
• D'Addario® EXL140

• string gauge
• .010/.013/.017/.030/.042/.052

• hardware color
• Gold

NECK DIMENSIONS

• Scale :
• 628mm

• a : Width
• 43mm at NUT

• b : Width
• 57mm at 22F

• c : Thickness
• 21mm at 1F

• d : Thickness
• 24mm at 9F

• Radius :
• 305mmR

BODY DIMENSIONS

• a : Length
• 19 1/4"

• b : Width
• 15 3/4"

• c : Max Depth
• 2 5/8"

SWITCHING SYSTEM

CONTROLS

Features

3pc Nyatoh/Maple neck

The 3pc Nyatoh/Maple Neck provides a rich mid-low end and great resonance.

Macassar Ebony fretboard

Macassar Ebony produces tight lows and mid range along with strong attack in the highs and quick response with rich sustain.

Gibraltar Performer bridge

The Gibraltar Performer bridge provides rich sustain and tuning stability. The low-positioned saddles promise comfortable playability.

Super 80 pickups

The legendary Super 80 pickups with iconic "Flying Finger" engraving on the covers deliver a bright and clean tone.

Quik Change Classic tailpiece

The Quik Change Classic tailpiece enables faster and easier string changing.
