Nánari lýsing
In facts, FMX’s horn design allows a very precise dispersion pattern (60° horizontal and 90° vertical) which can be easily reversed (90° horizontal and 60° vertical) by rotating the horn, adapting the wedge to the habits of the user.
Moreover, 8 on-board presets optimize EQ for different needs making FMX a skilful yet easy-to-use tool for performers of every kind.
All wedges of the series feature a peculiar front-rear grille design, a single handle integrated on the bottom side of the plywood cabinet and a 36mm pole mount on side panel which further enhance FMX versatility.
Technical Data
Speaker Type - 2-Way Active Coaxial Stage Monitor
Acoustical data
Frequency Response [- 10 dB] - 52 - 19.000 Hz
Max SPL - 128 dB
HF - 1", 1.3" v.c.
Directivity - 60°X90°
Horn - Rotatable
LF - 12", 2" v.c.
Amplifier
Amp Class - Class D
Peak Power - 1200 W
Processor
Controller - DSP 28/56 bit
AD/DA Converter - 24 bit/48 kHz
System Presets - 8 presets
Limiter - Peak, RMS, Thermal
Advanced DSP Function - FIR Filters
Crossover Frequency - 1740 Hz
Slope LF/HF - 24 dB/oct
Mechanics
Housing - Plywood
Housing Design - Multifunctional
Handles - 1 integrated on bottom side
Pole mount - 36 mm
Width - 465 mm (18.30 in)
Height - 297 mm (11.69 in)
Depth - 444 mm (17.48 in)
Weight - 13.9 kg (30.6 lbs)
