Origin Effects BassRIG Super Vintage
The BASSRIG Super Vintage is, quite simply, a complete vintage bass amp in a pedal. Based on the iconic Ampeg® SVT®, we have used all-analogue circuitry to recreate a complete valve amp-style signal path, along with an all-analogue cabinet simulator, giving you all the warmth, feel and drive of this classic bass rig in one small box.
When the SVT® arrived on the scene in 1969, it rewrote the rulebook for purpose-built bass amplification. Thanks to its enormous power, deep bass, growling overdrive and purposeful control set, this tower of tone has remained the amp of choice for the most discerning bassists on the world’s biggest stages.
With XLR and ¼” outputs, the BASSRIG Super Vintage will fit seamlessly into any signal chain, no matter how simple or complex, and our powerful Amp Out EQ tailors your sound to work with any amp, meaning you never have to compromise on tone.
Nánari lýsing
SPECIFICATIONS
Physical
Weight
846 g (1.86 lb)
Dimensions
146 × 93 × 65 mm (5.74 x 3.6 x 2.5 in.)
L x W x H - Includes knobs and switches
Electrical
Input Impedance
1 MΩ
Output Impedance
500 Ω
Current Draw
150 mA
Power
Power Supply
9V DC 2.1 mm centre-negative
Please note: the BASSRIG is powered by a mains adaptor only (not included). We’ve dispensed with the usual 9V battery option, both to save space and to allow us to adopt a high-current approach, yielding lower noise levels and superior tone.
Origin Effects pedals are designed to deliver impeccable performance using a range of power supplies. We recommend you only use a regulated power supply specifically designed for guitar pedal applications as power supplies which do not have sufficient internal filtering can result in unwanted noise.
We recommend the following power supplies for use with our pedals:
- Voodoo Labs Pedal Power series
- Cioks supplies
- Truetone 1 Spot Pro series
- Strymon Zuma
This product should only be operated at 9V. The design employs a voltage doubling circuit to achieve higher internal voltages for improved sonic performance.
